UNIVERSAL CLAMP
Clamp Style for Standing Seam Roofs
Available this summer - The Snow Stop Clamp-Style Rail system delivers strong, non-penetrative snow retention for standing seam roofs in light to extreme snow conditions. it features a lightweight, corrosion-resistant polymer design with fast clamp-on installation, supports single or double rail configurations, while reducing roof load, install time, and long-term maintenance compared to traditional metal systems.
7X
lighter than steel
- 40°C
tested and rated
UV+
fade resistance
Specifications
-
Material: TitanCore™ Head, Annodized Aluminum Base
-
Seam Compatibility: Mechanical Single/Double, Snaplock Verticle, Snaplock Narrow, Snaplock Traditional, Batten Lock
-
Maximum Load: 1,500lbs/ft (Brackets spaced every 18"-24")
-
Optimal Snowfall Range: Light - Extreme
-
Optimal Roof Pitch Use: 3:12 - 12:12
Colour Available
Black
Components
Performance
Rails
Clamps
Accessories
Rail Length: 7'
Weight: 2.46lbs/1.1kg
Rails rated for 3,000lbs per linear foot
1 Hole (1"-3")
1 Hole (1"-3")
Weight: 7.0oz/200g
Vertical Pull Test: 1,500lbs
Horizontal Drag Test: 400lbs
-
304 Stainless Steel Screw
-
POM Nylon Tips (-50°C / -58°F) Nylon Patch Pre Installed
-
Compatible with 10mm bit
-
Joiners (Friction fit)
-
End Caps (Friction fit)
-
Ice Blocker
Testing
Corrosion Resistance: 100% Rust-Proof Polymer, No Coatings Required
UV & Colour Retention:
Fully UV-Stabilized, Fade-Resistant Colours Integrated Throughout Polymer
Thermal Stability:
Operating Range -40°C (-40°F) to +70°C (+158°F)
Minimal Thermal Expansion & Contraction
Install in Minutes
Fast to lay out
Quick to Secure
Torque, Lock, Done
Friction fit joiners and end caps to finish your project off.
